B4G12U (412U)

B4G12U ; Philips Electrical, (ID = 721216) Radio

B4G12U ; Philips Electrical, (ID = 721217) Radio

B4G12U ; Philips Electrical, (ID = 721219) Radio

B4G12U ; Philips Electrical, (ID = 721222) Radio
Use red slider bar for more.
B4G12U ; Philips Electrical, (ID = 721216) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Great Britain (UK)
Manufacturer / Brand:  Philips Electrical, Lamps, Industrial - Miniwatt; London
Year: 1962 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UCC85 UCH81 UF89 UABC80 UL84 UY85
Main principle Superheterodyne (common); ZF/IF 470/10700 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage AC/DC-set / 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: B4G12U - Philips Electrical, Lamps,
Shape Tablemodel, with any shape - general.
Notes Same chassis as model B3G99U.
Source of data -- Schematic
Literature/Schematics (1) Radio And Television Servicing books (R&TVS)

Model page created by Keith Staines. See "Data change" for further contributors.
