B4G17U; Philips Electrical, (ID = 777793) Radio
Philips Electrical,: B4G17U [Radio] ID = 777793 633x476
Select picture or schematic to display from thumbnails on the right and click for download.
For model B4G17U, Philips Electrical, Lamps, Industrial - Miniwatt; London:
Thanks for Mr.Aradi József, Hungary!

Country:  Great Britain (UK)
Manufacturer / Brand:  Philips Electrical, Lamps, Industrial - Miniwatt; London
Year: 1963 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UCC85 UCH81 UF89 UABC80 UL84 UY85
Main principle Superheterodyne (common); ZF/IF 470/10700 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)     8 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage AC/DC-set / 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: B4G17U - Philips Electrical, Lamps,
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 21.25 x 10.5 x 8.5 inch / 540 x 267 x 216 mm
Notes Speaker 6 x 4 inches. Chassis similar to model F4G20A & Stella model ST145U. Price £25.6s.8d. plus Tax.
Price in first year of sale 25.00 GBP
Circuit diagram reference Radio and TV Servicing books (R&TVS) book
Literature/Schematics (1) -- Schematic (Trader Sheet 1649)

Model page created by Keith Staines. See "Data change" for further contributors.
