• Year
  • 1950
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 106827

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • AC/DC-set / 115 Volt
  • Material
  • Bakelite case
  • from Radiomuseum.org
  • Model: BF101U - Philips France; Paris
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Dimensions (WHD)
  • 225 x 125 x 135 mm / 8.9 x 4.9 x 5.3 inch
  • Net weight (2.2 lb = 1 kg)
  • 2 kg / 4 lb 6.5 oz (4.405 lb)
  • Source of data
  • -- Original-techn. papers.
  • Author
  • Model page created by John Koster. See "Data change" for further contributors.
