BF184U /03

BF184U /03; Philips France; (ID = 2244954) Radio BF184U /03; Philips France; (ID = 2244957) Radio
BF184U /03; Philips France; (ID = 2244955) Radio BF184U /03; Philips France; (ID = 2244956) Radio
BF184U /03; Philips France; (ID = 1637156) Radio BF184U /03; Philips France; (ID = 569340) Radio
BF184U /03; Philips France; (ID = 569338) Radio BF184U /03; Philips France; (ID = 570253) Radio
Use red slider bar for more.
BF184U /03; Philips France; (ID = 2244954) Radio
Philips France;: BF184U /03 [Radio] ID = 2244954 1400x1072
Select picture or schematic to display from thumbnails on the right and click for download.
For model BF184U /03, Philips France; Paris

Country:  France
Manufacturer / Brand:  Philips France; Paris
Year: 1949 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH42 UAF42 UBC41 UL41 UY42
Main principle Super-Heterodyne (Super in general); ZF/IF 452 kHz; 2 AF stage(s); none
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage AC/DC-set / 127 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
Power out 2.5 W (unknown quality)
from Radiomuseum.org Model: BF184U /03 - Philips France; Paris
Material Bakelite case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 250 x 170 x 150 mm / 9.8 x 6.7 x 5.9 inch
Net weight (2.2 lb = 1 kg) 2.5 kg / 5 lb 8.1 oz (5.507 lb)
Price in first year of sale 11'290.00 FF
Collectors' prices

Model page created by Erik Sipkema. See "Data change" for further contributors.
