BF281U

BF281U; Philips France; (ID = 965744) Radio

BF281U; Philips France; (ID = 965743) Radio

BF281U; Philips France; (ID = 965742) Radio

BF281U; Philips France; (ID = 1215474) Radio
BF281U; Philips France; (ID = 2164086) Radio BF281U; Philips France; (ID = 1668732) Radio
BF281U; Philips France; (ID = 215184) Radio BF281U; Philips France; (ID = 215185) Radio
BF281U; Philips France; (ID = 215187) Radio BF281U; Philips France; (ID = 215188) Radio
BF281U; Philips France; (ID = 1226917) Radio BF281U; Philips France; (ID = 1668733) Radio
BF281U; Philips France; (ID = 1668735) Radio BF281U; Philips France; (ID = 1668736) Radio
Use red slider bar for more.
BF281U; Philips France; (ID = 2164086) Radio
Philips France;: BF281U [Radio] ID = 2164086 1400x1210
Select picture or schematic to display from thumbnails on the right and click for download.
For model BF281U, Philips France; Paris

Country:  France
Manufacturer / Brand:  Philips France; Paris
Year: 1948 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH41 UAF41 UAF41 UL41 UY41
Main principle Super-Heterodyne (Super in general); ZF/IF 472 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 110-125; 200-220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 11 cm = 4.3 inch
Power out
from Radiomuseum.org Model: BF281U - Philips France; Paris
Material Bakelite case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 250 x 180 x 150 mm / 9.8 x 7.1 x 5.9 inch
Notes

Siehe auch Radiola RA82U.

Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
Collectors' prices

Model page created by Klaus Menningen. See "Data change" for further contributors.



All listed radios etc. from Philips France; Paris
Here you find 544 models, 482 with images and 297 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Philips France;: BF281U
Threads: 1 | Posts: 2
Hits: 1465     Replies: 1
philips: BF281U; Scan von Skala
Peter Breu
12.Sep.13
  1

Hallo,

ich bräuchte einen guten Scan von der Skala, da meine verwischt ist.

Oder hat jemand ein Sclachtgerät mit intakter Skala?

MfG

Peter Breu

Hans-Werner Ellerbrock
02.Mar.14
  2

Hallo Herr Breu!

Haben Sie unser Mitglied Klaus Menningen schon wg. des Scans gefragt? Er ist als Bild-Hochlader dieses Modells verzeichnet.

Viel Erfolg bei der Rekonstruktion wünscht

Hans-W.Ellerbrock
