BF401A; Philips France; (ID = 721331) Radio
Philips France;: BF401A [Radio] ID = 721331 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model BF401A, Philips France; Paris

Country:  France
Manufacturer / Brand:  Philips France; Paris
Year: 1950–1952 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: UCH42 UAF42 UBC41 UL41 UM4 UY41
Main principle Super-Heterodyne (Super in general)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage AC/DC-set / 110-220Volt Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 19 cm = 7.5 inch
Power out
from Radiomuseum.org Model: BF401A - Philips France; Paris
Material Bakelite case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 450 x 290 x 190 mm / 17.7 x 11.4 x 7.5 inch
Net weight (2.2 lb = 1 kg) 7.6 kg / 16 lb 11.8 oz (16.74 lb)
Price in first year of sale 22'900.00 FRF
Collectors' prices
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Ralf Plaga. See "Data change" for further contributors.



All listed radios etc. from Philips France; Paris
Here you find 544 models, 482 with images and 297 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
