BF473A

BF473A; Philips France; (ID = 1844771) Radio

BF473A; Philips France; (ID = 1844769) Radio
BF473A; Philips France; (ID = 1844768) Radio
Use red slider bar for more.
BF473A; Philips France; (ID = 1844768) Radio
Philips France;: BF473A [Radio] ID = 1844768 1156x895
Select picture or schematic to display from thumbnails on the right and click for download.
For model BF473A, Philips France; Paris:
Photo issue de la documentation technique Philips

Country:  France
Manufacturer / Brand:  Philips France; Paris
Year: 1948 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH3 ECF1 EBL1 AZ1 EM4
Main principle Super-Heterodyne (Super in general); ZF/IF 472 kHz
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch
Power out
from Radiomuseum.org Model: BF473A - Philips France; Paris
Material Moulded (Bakelite or Plastics)
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 400 x 300 x 220 mm / 15.7 x 11.8 x 8.7 inch
Notes

Documentation de base = BF471A

Net weight (2.2 lb = 1 kg) 7.5 kg / 16 lb 8.3 oz (16.52 lb)
Price in first year of sale 25'450.00 FRF

Model page created by Karsten Hauger. See "Data change" for further contributors.
