BTR430A
Use red slider bar for more.
Philips TURKEY ;: BTR430A [Radio] ID = 2091918 1400x1212
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1953 ? | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 6: ECH81 EBF80 EBC41 EL84 DM71 EZ80 |
|---|
| Main principle | Superheterodyne (common); ZF/IF 452 kHz |
|---|---|
| Tuned circuits | 6 AM circuit(s) |
| Wave bands | Broadcast, Long Wave and 2 x Short Wave. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 110; 127; 145; 220 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm |
| Power out | |
| from Radiomuseum.org | Model: BTR430A - Philips TURKEY ; Istanbul |
| Material | Bakelite case |
| Shape | Tablemodel, low profile (big size). |
| Dimensions (WHD) | 470 x 320 x 220 mm / 18.5 x 12.6 x 8.7 inch |
| Notes | See also the similar model BX430A /10 from Philips Holland. |
| Net weight (2.2 lb = 1 kg) | 6.6 kg / 14 lb 8.6 oz (14.537 lb) |
Model page created by Mehmet Danki. See "Data change" for further contributors.
