BTR 335 A
Use red slider bar for more.
Philips TURKEY ;: BTR 335 A [Radio] ID = 2397450 1400x1049
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1955 ? | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 5: ECH81 EBF80 EBC41 EL84 EZ80 |
|---|
| Main principle | Superheterodyne (common); ZF/IF 455 kHz |
|---|---|
| Wave bands | Broadcast, Long Wave and Short Wave. |
| Details | |
| Power type and voltage | Alternating Current supply (AC) / 110; 127; 145; 220 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 18 cm = 7.1 inch |
| Power out | |
| from Radiomuseum.org | Model: BTR 335 A - Philips TURKEY ; Istanbul |
| Material | Bakelite case |
| Shape | Tablemodel, low profile (big size). |
| Dimensions (WHD) | 375 x 275 x 185 mm / 14.8 x 10.8 x 7.3 inch |
| Notes | 3 Wave band LW: 1150-2000 mt. MW: 180-600 mt. SW: 16-50 mt. |
| Net weight (2.2 lb = 1 kg) | 6.250 kg / 13 lb 12.3 oz (13.767 lb) |
Model page created by Ekrem Cengiz Bilgin. See "Data change" for further contributors.
