• Country
• Brazil

• Manufacturer / Brand
• Philips do Brasil S.A.

• Year
• 1980 ??

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 326712

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 16

• Semiconductors
• BC337 BC548 BC548 BC548 BC548 BC548 BC548 BC548 BC548 BC548 BC548 BC548 BC548 BC548 BC548 BC548 BA314 BA314 BA314 BA314 BA314 BA314 BA314 1N4001 1N4001 1N4001 BZX79

• Wave bands
• - without

• Details
• Hi-Fi equipment

• Power type and voltage
• No Power needed

• Loudspeaker
• 4 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Caixa acústica 06AH487 - Philips do Brasil S.A.

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 454 x 715 x 360 mm / 17.9 x 28.1 x 14.2 inch

• Notes
• • Hi Fi speaker box, bass reflex type, 3 way system
  • Power handling capacity 50 Watts rms
  • Impedance 8 Ohms
  • Frequency response 35 Hz to 20 kHz (-3 dB)
  • Internal volume 70 liters
  • Detachable front panel
  • Dome tweeter
  • Power indicator ledbar
  • Tweeter and mid range attenuators (-3dB, -6dB and -9 dB)
