Cassetten-Recorder EL3302A /00G 9 Transistoren

Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 443907) R-Player

Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 1620061) R-Player

Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 451941) R-Player

Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 443908) R-Player

Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 451944) R-Player

Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 451945) R-Player

Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 443909) R-Player

Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 692575) R-Player

Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 1333604) R-Player

Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 1333606) R-Player
Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 470019) R-Player Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 272778) R-Player
Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 752320) R-Player Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 1462265) R-Player
Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 1462267) R-Player Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 1486720) R-Player
Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 1486721) R-Player Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 1486722) R-Player
Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 1486736) R-Player Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 1742633) R-Player
Use red slider bar for more.
Cassetten-Recorder EL3302A /00G; Philips - Österreich (ID = 470019) R-Player
Philips - Österreich: Cassetten-Recorder EL3302A /00G [R-Player] ID = 470019 375x500
Select picture or schematic to display from thumbnails on the right and click for download.
For model Cassetten-Recorder EL3302A /00G 9 Transistoren, Philips - Österreich

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1968 ? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 9: BC149 BC148 BC148 BC148 AC187 AC188 AC127 AC127 AC128
Main principle Audio-Amplification; none
Wave bands - without
Details Cassette-Recorder or -Player
Power type and voltage Batteries / addl. power jack / C: 5 x 1,5 / 7,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 cm = 2.4 inch
Power out 0.4 W (unknown quality)
from Radiomuseum.org Model: Cassetten-Recorder EL3302A /00G [9 Transistoren] - Philips - Österreich
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 115 x 55 x 200 mm / 4.5 x 2.2 x 7.9 inch
Notes

Minus an Masse.

Net weight (2.2 lb = 1 kg) 1.3 kg / 2 lb 13.8 oz (2.863 lb)
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Holger Ortmann. See "Data change" for further contributors.



All listed radios etc. from Philips - Österreich
Here you find 1055 models, 991 with images and 854 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Philips - Österreich: Cassetten-Recorder EL3302A /00G
Threads: 1 | Posts: 1
Hits: 2887     Replies: 0
philips: EL3302A/00G (EL 3302 A/00 G); Cassetten-
Martin Rathgeber
05.Mar.10
  1

Zum Herstellungsjahr:

In "Aktenzeichen XY" vom 02.04. 1971 wird ein solcher Kassettenrecorder vorgestellt, der Anfang 1967 angeboten worden sein sollte.

siehe

http://www.youtube.com/watch#!v=g9lL3KOj7ao&feature=PlayList&p=BD8C1C65C5C2F1D4&playnext=1&playnext_from=PL&index=6


Philips - Österreich: Cassetten-Recorder EL3302A /00G
