Chansonette 03RL371 /05R /05Z; Philips - Österreich (ID = 255948) Radio
Philips - Österreich: Chansonette 03RL371 /05R /05Z [Radio] ID = 255948 933x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model Chansonette 03RL371 /05R /05Z, Philips - Österreich

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1967/1968 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: AF121 AF124 AF126 AF126 AF126 AC125 AC127 AC127 AC128 AC128
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz; 5 AF stage(s)
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Dry Batteries / 4 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.55 W (unknown quality)
from Radiomuseum.org Model: Chansonette 03RL371 /05R /05Z - Philips - Österreich
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 240 x 150 x 65 mm / 9.4 x 5.9 x 2.6 inch
Notes 2 Ausführungen:
/05R = hart/schwarz
/05Z = hart/teak
Parallelgerät zum Horny W7317/05.
Net weight (2.2 lb = 1 kg) 1.8 kg / 3 lb 15.4 oz (3.965 lb)
Source of data -- Original-techn. papers. / Radiokatalog Band 2, Ernst Erb

Model page created by Wolfgang Bauer. See "Data change" for further contributors.
