Compact-Philetta 861 TAC 22AB861

Philips - Österreich

  • Year
  • 1976/1977
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 117569

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 25
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz
  • Tuned circuits
  • 6 AM circuit(s)     11 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Details
  • Other Combination - see Notes
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Compact-Philetta 861 TAC 22AB861 - Philips - Österreich
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 508 x 161 x 338 mm / 20 x 6.3 x 13.3 inch
  • Notes
  • ICs: 2.
    Stereo-Steuergerät mit eingebautem Kasettenrecorder N2503; NF-Verstärker mit 2 Endstufen je 8 W (Sinus); zwei Lautsprecherboxen (220×300×140 mm) im Lieferumfang.
  • Mentioned in
  • -- Original-techn. papers.
