• Country
• Austria

• Manufacturer / Brand
• Philips - Österreich

• Year
• 1965 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 326664

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 13

• Semiconductors
• AC107 OC75 OC44 AC107 OC75 OC44 AC125 AC128 AC128 AC125 AC128 AC128 OC75

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 245 Volt

• Loudspeaker
• 2 Loudspeakers

• Power out
• 1.6 W (unknown quality)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: CR1607 /00 - Philips - Österreich

• Dimensions (WHD)
• 390 x 180 x 330 mm / 15.4 x 7.1 x 13 inch

• Notes

• Philips CR1607 /00, Stereo Tonbandgerät mit 4 Spuren und 2 Geschwindigkeiten (4,75 und 9,5 cm/s).

  Lautsprecher 1: permanent magnetisch, Durchmesser 10 cm.
  Lautsprecher 2: permanent magnetisch, Oval 10 x 15 cm.

  Ausgangsleistung: 2 x 800 mW.

  Siehe auch Modelle Philips EL3547A und Siera SA6147A.

• Net weight (2.2 lb = 1 kg)
• 9 kg / 19 lb 13.2 oz (19.824 lb)

• Author
• Model page created by Vladimir Jirkal. See "Data change" for further contributors.
