• Year
  • 1980 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 77500

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 220; Volt
  • Loudspeaker
  • 2 Loudspeakers
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: D2902 - Philips Italy; Milano MI
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 535 x 130 x 160 mm / 21.1 x 5.1 x 6.3 inch
  • Notes
  • 4 abstimmbare UKW Stationstasten. Volltransistorgerät mit abstimmbaren Tasten für UKW Empfang Drehrad für Abstimmung LW und MW. (4 pulsanti di preselezione stazioni FM; manopole di sintonia per OL e OM. Manuale istruzioni su http://www.p4c.philips.com/files/d/d2902/d2902_dfu_ita.pdf )
  • Net weight (2.2 lb = 1 kg)
  • 2.5 kg / 5 lb 8.1 oz (5.507 lb)
