Dürer 66 - D26K986 Ch= K7N
Philips Radios - Deutschland
- Country
- Germany
- Manufacturer / Brand
- Philips Radios - Deutschland
- Year
- 1970
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 104718
-
- Brand: Deutsche Philips-Ges.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 14
- Number of Transistors
- 54
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Details
- Radio Control (+Remote Wire etc)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Dürer 66 - D26K986 Ch= K7N - Philips Radios - Deutschland
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 740 x 530 x 590 mm / 29.1 x 20.9 x 23.2 inch
- Notes
- 61 Dioden, 1 IC. Röhren teilweise mehrfach vorhanden. Tuner mit Kapazitätsdioden für VHF und UHF.
- Mentioned in
- -- Original-techn. papers.
- Literature/Schematics (1)
- -- Schematic
- Author
- Model page created by Franz Born †. See "Data change" for further contributors.
