• Country
• Germany

• Manufacturer / Brand
• Philips Radios - Deutschland

• Year
• 1968

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 104303

• • Brand: Deutsche Philips-Ges.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 27

• Valves / Tubes
• PCL86 EF183 EF184 PCF200 PFL200 PCH200 PCF802 PL504 PL509 PY500 DY51 PCC85 PL508 PCF201 A63-11X

• Number of Transistors
• 16

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Dürer L D25K885 Ch= K6N - Philips Radios - Deutschland

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 730 x 530 x 560 mm / 28.7 x 20.9 x 22 inch

• Notes

• Röhren teilweise mehrfach vorhanden; 71 Dioden; Tuner mit Kapazitätsdioden für VHF und UHF.

• Net weight (2.2 lb = 1 kg)
• 50 kg / 110 lb 2.1 oz (110.132 lb)

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Franz Born †. See "Data change" for further contributors.
