EL3542A /15E

EL3542A /15E; Philips Electrical, (ID = 595054) R-Player

EL3542A /15E; Philips Electrical, (ID = 595055) R-Player
EL3542A /15E; Philips Electrical, (ID = 1067853) R-Player EL3542A /15E; Philips Electrical, (ID = 1067855) R-Player
EL3542A /15E; Philips Electrical, (ID = 989361) R-Player EL3542A /15E; Philips Electrical, (ID = 1067854) R-Player
Use red slider bar for more.
EL3542A /15E; Philips Electrical, (ID = 1067853) R-Player
Philips Electrical,: EL3542A /15E [R-Player] ID = 1067853 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model EL3542A /15E, Philips Electrical, Lamps, Industrial - Miniwatt; London

Country:  Great Britain (UK)
Manufacturer / Brand:  Philips Electrical, Lamps, Industrial - Miniwatt; London
Year: 1960 Category: Sound/Video Recorder and/or Player
Valves / Tubes 5: EF86 ECC83 ECL82 EZ80 EM81
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: EL3542A /15E - Philips Electrical, Lamps,
Shape Tablemodel, with any shape - general.
Notes Portable tape recorder. Three speed 7.5, 3.75 & 1.875 ips, four track, spool size 7 inch. Provision for use with external stereo amplifier.
Net weight (2.2 lb = 1 kg) 13.6 kg / 29 lb 15.3 oz (29.956 lb)
Source of data -- Schematic
Circuit diagram reference Radio and TV Servicing books (R&TVS) book
Documents about this model
  Philips EL3542A 971 KB

Model page created by Keith Staines. See "Data change" for further contributors.
