Elysee 650 24B650 /50Z Ch= E2

Philips - Österreich

  • Year
  • 1976
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 113120

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 1
  • Number of Transistors
  • Semiconductors present.
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 2 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Elysee 650 24B650 /50Z Ch= E2 - Philips - Österreich
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 665 x 490 x 390 mm / 26.2 x 19.3 x 15.4 inch
  • Notes
  • Empfangsbereiche VHF und UHF.
    Zwei verschiedene Chassis, abhängig in welchem der 3 Philips Werke das Gerät gefertigt wurde (Krefeld, Wien oder PYE).
  • Net weight (2.2 lb = 1 kg)
  • 22 kg / 48 lb 7.3 oz (48.458 lb)
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Wolfgang Bauer. See "Data change" for further contributors.
