Foajé L4S37T Ch= T7C-a
Use red slider bar for more.
Philips, Svenska AB,: Foajé L4S37T Ch= T7C-a [Radio] ID = 2506972 1400x1101
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
| Year: 1963 ? | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Semiconductors (the count is only for transistors) | 9: AF114 AF115 AF116 AF116 AF116 OC75 OC75 OC74 OC74 OA79 OA79 OA79 E25C5 |
|---|
| Main principle | Superhet with RF-stage; ZF/IF 460/6750 kHz |
|---|---|
| Tuned circuits | 6 AM circuit(s) 9 FM circuit(s) |
| Wave bands | Broadcast, Long Wave and FM or UHF. |
| Details | |
| Power type and voltage | Batteries / addl. power jack / D: 4 x 1.5 / 6 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical |
| Power out | 0.75 W (max.) |
| from Radiomuseum.org | Model: Foajé L4S37T Ch= T7C-a - Philips, Svenska AB, Stockholm |
| Material | Wooden case |
| Shape | Portable set > 8 inch (also usable without mains) |
| Dimensions (WHD) | 310 x 185 x 100 mm / 12.2 x 7.3 x 3.9 inch |
| Notes | Philips Foajé L4S37T is a battery operated 3-band transistorized portable AM/FM receiver. Bands:
Loudspeaker 4" x 6", type 0 4654-D Z= 7Ω Connections for battery eliminator BT-1, car antenna and headphones |
| Net weight (2.2 lb = 1 kg) | 2.9 kg / 6 lb 6.2 oz (6.388 lb) |
| Literature/Schematics (1) | -- Original-techn. papers. |
Model page created by Bernhard Nagel. See "Data change" for further contributors.
