For model H3F64A - HF364A, Philips France; Paris:
Publicité 1957

Country:  France
Manufacturer / Brand:  Philips France; Paris
Year: 1956–1959 perfect model Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: UCH81 UAF42 UL41 UY42
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 117; 127; 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
Power out
from Radiomuseum.org Model: H3F64A - HF364A - Philips France; Paris
Material Bakelite case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 395 x 205 x 310 mm / 15.6 x 8.1 x 12.2 inch
Notes

Antenne cadre microcapteur blindé.
Platine tourne-disque Philips AG2004 avec element AG3010.
Lampe cadran: 10 Volt / 200mA.

Equivalent au Radiola RA357A.

Utilisation inhabituelle de la lampe UCH81: La section heptode sert comme oscillateur et changeur de fréquence. La section triode sert comme premier amplificateur basse fréquence.

Le type HF364A est seulement mentionné dans les publicités; réellement le modèle est désigné H3F64A.

Net weight (2.2 lb = 1 kg) 7.450 kg / 16 lb 6.6 oz (16.41 lb)
Price in first year of sale 29'900.00 FRF
Mentioned in -- Original-techn. papers.
Literature/Schematics (1) -- Original prospect or advert (Gamme Novosonic 1959)

Model page created by Karsten Hauger. See "Data change" for further contributors.
