LIF 277B

LIF 277B; Philips Electrical (ID = 1278767) Radio

LIF 277B; Philips Electrical (ID = 1278768) Radio

LIF 277B; Philips Electrical (ID = 1278769) Radio

LIF 277B; Philips Electrical (ID = 1278770) Radio

LIF 277B; Philips Electrical (ID = 1278771) Radio

LIF 277B; Philips Electrical (ID = 1278773) Radio
LIF 277B; Philips Electrical (ID = 1278774) Radio
Use red slider bar for more.
LIF 277B; Philips Electrical (ID = 1278774) Radio
Philips Electrical: LIF 277B [Radio] ID = 1278774 730x795
Select picture or schematic to display from thumbnails on the right and click for download.
For model LIF 277B, Philips Electrical (Ireland) Ltd.; Dublin:
Extracted from original service manual

Country:  Ireland
Manufacturer / Brand:  Philips Electrical (Ireland) Ltd.; Dublin
Year: 1957 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: DK96 DF96 DAF96 DL96
Main principle Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 1,5 & 67,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 0.065 W (unknown quality)
from Radiomuseum.org Model: LIF 277B - Philips Electrical Ireland Ltd
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 10 x 5 x 3 inch / 254 x 127 x 76 mm
Notes May be similar to UK Philips L2G77B
Net weight (2.2 lb = 1 kg) 5.5 lb (5 lb 8 oz) / 2.497 kg
Source of data -- Original-techn. papers.

Model page created by Jose Casas-Avalos. See "Data change" for further contributors.
