For model LX444AB /01, Philips; Eindhoven (tubes international!); Miniwatt:
Bild aus ebay-163656500626-zauberklang-57

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1954/1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: DF96 DK92 DF96 DAF96 DM71 DL94
Main principle Superhet with RF-stage; ZF/IF 452 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Line / Batteries (any type) / AC 110; 125; 220 / 2 x 1,5 & 2 x 67,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 13 cm = 5.1 inch
Power out 0.35 W (unknown quality)
from Radiomuseum.org Model: LX444AB /01 - Philips; Eindhoven tubes
Material Bakelite case
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 260 x 245 x 135 mm / 10.2 x 9.6 x 5.3 inch
Notes

5 colors available: ../01 = brown, ../2 = green, ../03 = red, ../04 = white and ../05 = blue.
Brown case is made of bakelite, other cases are plastic.
Two flashlight cells plus 2 Berec B101 HT batteries. HT batteries can be refreshed using the built-in battery charger.
Weight includes batteries.

Gehäusefarbe braun.
Siehe auch das Basismodell LX444AB.

Net weight (2.2 lb = 1 kg) 4.5 kg / 9 lb 14.6 oz (9.912 lb)
Price in first year of sale 178.00 Hfl
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Wolfgang Bauer. See "Data change" for further contributors.
