Motoradio 574V

Motoradio 574V; Philips Electrical, (ID = 546262) Car Radio

Motoradio 574V; Philips Electrical, (ID = 546263) Car Radio

Motoradio 574V; Philips Electrical, (ID = 546265) Car Radio
Motoradio 574V; Philips Electrical, (ID = 2064286) Car Radio Motoradio 574V; Philips Electrical, (ID = 2064287) Car Radio
Motoradio 574V; Philips Electrical, (ID = 2064289) Car Radio Motoradio 574V; Philips Electrical, (ID = 2064290) Car Radio
Use red slider bar for more.
Motoradio 574V; Philips Electrical, (ID = 2064286) Car Radio
Philips Electrical,: Motoradio 574V [Car Radio] ID = 2064286 1024x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model Motoradio 574V, Philips Electrical, Lamps, Industrial - Miniwatt; London:
Ebay UK item number 262775233801 seller lynnwalke53

Country:  Great Britain (UK)
Manufacturer / Brand:  Philips Electrical, Lamps, Industrial - Miniwatt; London
Year: 1950 Category: Car Radio, perhaps also + sound player/recorder
Valves / Tubes 5: ECH42 EF41 EBC41 EL42 EZ41
Main principle Superheterodyne (common); ZF/IF 470 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 6/12 Volt
Loudspeaker
Power out
from Radiomuseum.org Model: Motoradio 574V - Philips Electrical, Lamps,
Source of data -- Schematic
Literature/Schematics (1) Radio And Television Servicing books (R&TVS)

Model page created by Keith Staines. See "Data change" for further contributors.
