• Country
• Austria

• Manufacturer / Brand
• Philips - Österreich

• Year
• 1977/1978

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 125271

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 5

• Semiconductors
• BC109 BC109 BC548 BC548 BC548

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 220 / 6×1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Stereo Recorder N2415 - Philips - Österreich

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 260 x 70 x 200 mm / 10.2 x 2.8 x 7.9 inch

• Notes
• 2 Ausführungen: ../60 und ../65.
  Bei Wiedergabe über den eingebauten Lautsprecher werden beide Kanäle L+R auf den eingebauten LS geschalten
  Stereo-Cassetten-Recorder. Eingebautes Electret-Mikrofon; automatische Aussteuerung; Frequenzbereich: 80···11000 Hz. Ausgangsleistung: 2× 1,5 W (Musik).

• Net weight (2.2 lb = 1 kg)
• 2 kg / 4 lb 6.5 oz (4.405 lb)

• Source of data
• Handbuch VDRG 1977/1978

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
