• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1957/1958

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 30262

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• ECH81 EBF80 EBC81 EL95

• Number of Transistors

• Semiconductors
• AP6002

• Main principle
• Superheterodyne (common); ZF/IF 452 kHz

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Storage and/or dry batteries / 6/12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: N3X72V/10 - Philips; Eindhoven tubes

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 180 x 80 x 180 mm / 7.1 x 3.1 x 7.1 inch

• Notes
• Conical shape, front height: 50 mm.
  Vibrator (chopper, Zerhacker) type AP6002.

• Net weight (2.2 lb = 1 kg)
• 3.1 kg / 6 lb 13.3 oz (6.828 lb)

• Price in first year of sale
• 2,595.00 BFr

• Author
• Model page created by Iven Müller. See "Data change" for further contributors.
