For model All-Transistor N4X41T /19, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1964/1965 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 10: AF102 AF124 AF185 AF126 AF126 AF126 AC125 AC128 AD139 AD139
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Storage and/or dry batteries / 6/12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 3 W (unknown quality)
from Radiomuseum.org Model: All-Transistor N4X41T /19 - Philips; Eindhoven tubes
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 181 x 54 x 175 mm / 7.1 x 2.1 x 6.9 inch
Notes

Paralleltype zum N4X41T /00 mit ZF 452kHz.

Net weight (2.2 lb = 1 kg) 1.7 kg / 3 lb 11.9 oz (3.744 lb)
Literature/Schematics (1) -- Original-techn. papers.
