N4X41T /00; Philips; Eindhoven (ID = 32613) Car Radio
Philips; Eindhoven: N4X41T /00 [Car Radio] ID = 32613 543x348
Select picture or schematic to display from thumbnails on the right and click for download.
For model N4X41T /00, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1964/1965 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 10: AF102 AF124 AF185 AF126 AF126 AF126 AC125 AC128 AD139 AD139
Main principle Superheterodyne (common); ZF/IF 452/10700 kHz
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Storage and/or dry batteries / 6/12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 3 W (unknown quality)
from Radiomuseum.org Model: N4X41T /00 - Philips; Eindhoven tubes
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 181 x 54 x 175 mm / 7.1 x 2.1 x 6.9 inch
Notes

Paralleltype zum N4X41T /19 mit ZF 460 kHz.

Literature/Schematics (1) -- Original-techn. papers.

Model page created by Iven Müller. See "Data change" for further contributors.
