N5X47T; Philips; Eindhoven (ID = 48448) Car Radio

N5X47T; Philips; Eindhoven (ID = 48449) Car Radio

N5X47T; Philips; Eindhoven (ID = 48450) Car Radio

N5X47T; Philips; Eindhoven (ID = 48451) Car Radio

N5X47T; Philips; Eindhoven (ID = 48452) Car Radio
N5X47T; Philips; Eindhoven (ID = 32597) Car Radio N5X47T; Philips; Eindhoven (ID = 145874) Car Radio
N5X47T; Philips; Eindhoven (ID = 1486365) Car Radio N5X47T; Philips; Eindhoven (ID = 1486366) Car Radio
N5X47T; Philips; Eindhoven (ID = 1486367) Car Radio N5X47T; Philips; Eindhoven (ID = 1486368) Car Radio
N5X47T; Philips; Eindhoven (ID = 1486369) Car Radio
Use red slider bar for more.
N5X47T; Philips; Eindhoven (ID = 32597) Car Radio
Philips; Eindhoven: N5X47T [Car Radio] ID = 32597 579x273
Select picture or schematic to display from thumbnails on the right and click for download.
For model N5X47T, Philips; Eindhoven (tubes international!); Miniwatt

Country:  Netherlands
Manufacturer / Brand:  Philips; Eindhoven (tubes international!); Miniwatt
Year: 1964/1965 Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 10: AF126 AF126 AF126 AF127 AF127 AC125 AC125 AC128 AD149 AD149
Main principle Superheterodyne (common); ZF/IF 452 kHz
Wave bands Broadcast only (MW).
Details
Power type and voltage Storage and/or dry batteries / 6/12 Volt
Loudspeaker
Power out 4 W (unknown quality)
from Radiomuseum.org Model: N5X47T - Philips; Eindhoven tubes
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 181 x 54 x 178 mm / 7.1 x 2.1 x 7 inch
Notes



Model page created by Iven Müller. See "Data change" for further contributors.
