Netzgerät PE1534

Netzgerät PE1534; Philips Belgium (ID = 967997) Equipment Netzgerät PE1534; Philips Belgium (ID = 967998) Equipment
Netzgerät PE1534; Philips Belgium (ID = 968000) Equipment Netzgerät PE1534; Philips Belgium (ID = 968001) Equipment
Netzgerät PE1534; Philips Belgium (ID = 968002) Equipment Netzgerät PE1534; Philips Belgium (ID = 968003) Equipment
Use red slider bar for more.
Netzgerät PE1534; Philips Belgium (ID = 967997) Equipment
Philips Belgium: Netzgerät PE1534 [Equipment] ID = 967997 933x605
Select picture or schematic to display from thumbnails on the right and click for download.
For model Netzgerät PE1534, Philips Belgium (Belgien)

Country:  Belgium
Manufacturer / Brand:  Philips Belgium (Belgien)
Year: 1975 ?? Category: Service- or Lab Equipment
Valves / Tubes 2: QQE06/40 QQE06/40
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details Power Supply (not only Batt.El.)
Power type and voltage Alternating Current supply (AC) / 110/235 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Netzgerät PE1534 - Philips Belgium Belgien
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 245 x 142 x 425 mm / 9.6 x 5.6 x 16.7 inch
Notes DC Ausgangsspannung: 350V-3500V regelbar mit 10 Gang Poti.
Ausgangsstrom: 0-10mA regelbar.
Net weight (2.2 lb = 1 kg) 11.1 kg / 24 lb 7.2 oz (24.449 lb)

Model page created by Rudolf Osterkamp. See "Data change" for further contributors.
