Olimpico 19RL283T/00R

Olimpico 19RL283T/00R; Philips Italy; (ID = 1413882) Radio

Olimpico 19RL283T/00R; Philips Italy; (ID = 1503677) Radio

Olimpico 19RL283T/00R; Philips Italy; (ID = 1503678) Radio

Olimpico 19RL283T/00R; Philips Italy; (ID = 1503679) Radio
Olimpico 19RL283T/00R; Philips Italy; (ID = 2360781) Radio Olimpico 19RL283T/00R; Philips Italy; (ID = 1412530) Radio
Olimpico 19RL283T/00R; Philips Italy; (ID = 2360782) Radio Olimpico 19RL283T/00R; Philips Italy; (ID = 2360783) Radio
Olimpico 19RL283T/00R; Philips Italy; (ID = 2360784) Radio Olimpico 19RL283T/00R; Philips Italy; (ID = 2360785) Radio
Olimpico 19RL283T/00R; Philips Italy; (ID = 2360786) Radio
Use red slider bar for more.
Olimpico 19RL283T/00R; Philips Italy; (ID = 2360781) Radio
Philips Italy;: Olimpico 19RL283T/00R [Radio] ID = 2360781 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Olimpico 19RL283T/00R, Philips Italy; Milano (MI)

Country:  Italy
Manufacturer / Brand:  Philips Italy; Milano (MI)
Year: 1968/1969 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: AF117 AF127 AC127 AC128 AC128 AC127 AC128 AA119
Main principle Superheterodyne (common); ZF/IF 460 kHz
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 3 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5.5 cm = 2.2 inch
Power out 0.15 W (unknown quality)
from Radiomuseum.org Model: Olimpico 19RL283T/00R - Philips Italy; Milano MI
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 182 x 113 x 41 mm / 7.2 x 4.4 x 1.6 inch
Notes

Gamma d'onda:
OM: 517 - 1635 kHz.
Presa auricolare.

controllo volume - antenna interna in ferrite - maniglia di trasporto.

Circuito stabilizzato Ecodyne.

Net weight (2.2 lb = 1 kg) 0.4 kg / 0 lb 14.1 oz (0.881 lb)
Source of data -- Original-techn. papers.
Mentioned in Guida Pratica Transistor Radios

Model page created by Eduard Abfalterer. See "Data change" for further contributors.
