P251
Philips Canada
- Country
- Canada
- Manufacturer / Brand
- Philips Canada
- Year
- 1956 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 295737
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast only (MW).
- Details
- Record Player (not changer)
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
- Power out
- 0.9 W (undistorted)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: P251 - Philips Canada
- Dimensions (WHD)
- 15 x 7.875 x 14 inch / 381 x 200 x 356 mm
- Notes
-
Same as Rogers R651.
- Literature/Schematics (1)
- Radio College of Canada (RCC) (1955/1956 Supplement 36)
- Author
- Model page created by Les Dickson. See "Data change" for further contributors.
- Other Models
-
Here you find 162 models, 90 with images and 138 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Philips Canada
