Philetta 204 de luxe B2D04U

Philetta 204 de luxe B2D04U; Philips Radios - (ID = 30727) Radio

Philetta 204 de luxe B2D04U; Philips Radios - (ID = 30728) Radio
Philetta 204 de luxe B2D04U; Philips Radios - (ID = 683675) Radio Philetta 204 de luxe B2D04U; Philips Radios - (ID = 920172) Radio
Philetta 204 de luxe B2D04U; Philips Radios - (ID = 132327) Radio Philetta 204 de luxe B2D04U; Philips Radios - (ID = 361518) Radio
Philetta 204 de luxe B2D04U; Philips Radios - (ID = 98263) Radio Philetta 204 de luxe B2D04U; Philips Radios - (ID = 98264) Radio
Philetta 204 de luxe B2D04U; Philips Radios - (ID = 98265) Radio Philetta 204 de luxe B2D04U; Philips Radios - (ID = 98266) Radio
Philetta 204 de luxe B2D04U; Philips Radios - (ID = 132316) Radio Philetta 204 de luxe B2D04U; Philips Radios - (ID = 920174) Radio
Use red slider bar for more.
Philetta 204 de luxe B2D04U; Philips Radios - (ID = 683675) Radio
Philips Radios -: Philetta 204 de luxe B2D04U [Radio] ID = 683675 800x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model Philetta 204 de luxe B2D04U, Philips Radios - Deutschland

Country:  Germany
Manufacturer / Brand:  Philips Radios - Deutschland
Brand

Deutsche Philips-Ges.
Year: 1960/1961 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: UCC85 UCH81 UF89 UABC80 UM80 UL84 UY85
Main principle Super-Heterodyne (Super in general); ZF/IF 460 kHz
Tuned circuits 6 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage AC/DC-set / 110, 127, 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Philetta 204 de luxe B2D04U - Philips Radios - Deutschland
Material Bakelite case
Dimensions (WHD) 330 x 200 x 170 mm / 13 x 7.9 x 6.7 inch
Notes Varianten: elfenbein, grün, rot und schwarz.
Net weight (2.2 lb = 1 kg) 3.2 kg / 7 lb 0.8 oz (7.048 lb)
Price in first year of sale 210.00 DM
Collectors' prices
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1960/61
