For model 855X, Philips akc. spol., Praha-Hloubetin:
855A-14

Country:  Czechoslovakia
Manufacturer / Brand:  Philips akc. spol., Praha-Hloubetin
Year: 1939/1940 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: EF8 ECH3 EF9 EBL1 EFM1 AZ1
Main principle Superhet with RF-stage; ZF/IF 468 kHz; 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
Power out 4.5 W (unknown quality)
from Radiomuseum.org Model: 855X - Philips akc. spol., Praha-
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 560 x 420 x 280 mm / 22 x 16.5 x 11 inch
Notes

9 Tasten: 6 Blitztasten für Sender nach freier Wahl (zylindrische Schiebekondensatoren 3-fach), 3 Tasten K-M-L, 2-stuf. Bandbreitenregelung. (Mechanik wie Aachen D62)

ZF auch 473 kHz.

Net weight (2.2 lb = 1 kg) 16.5 kg / 36 lb 5.5 oz (36.344 lb)
Collectors' prices
External source of data Erb
Source of data Ceskoslovenske prijimace 1933-1945, Baudys 1947
Mentioned in Handbuch der Funktechnik (Fortschritte B.5, S.50ff)
