Philitina B1D12A

Philips Radios - Deutschland

  • Year
  • 1961/1962
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 23824
    • Brand: Deutsche Philips-Ges.

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz
  • Tuned circuits
  • 6 AM circuit(s)     10 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
  • Power out
  • 2 W (unknown quality)
  • Material
  • Bakelite case
  • from Radiomuseum.org
  • Model: Philitina B1D12A - Philips Radios - Deutschland
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Dimensions (WHD)
  • 310 x 155 x 140 mm / 12.2 x 6.1 x 5.5 inch
  • Notes
  • Plattenantenne für LM, Wurfantenne für U.
    UKW-Bereich 87,5-100 MHz.

    Siehe auch Siera SA2127A und Dux SA2127A/79K.

    Typschild zeigt das Kürzel WA was für den Produktionsort
    Philips Apparatefabrik Wetzlar steht

  • Net weight (2.2 lb = 1 kg)
  • 2.4 kg / 5 lb 4.6 oz (5.286 lb)
  • Price in first year of sale
  • 185.00 DM
  • External source of data
  • Erb
  • Literature/Schematics (1)
  • -- Original-techn. papers.
