Premiere Automatic 22RB484 /62; Philips Finland - (ID = 1804454) Radio
Philips Finland -: Premiere Automatic 22RB484 /62 [Radio] ID = 1804454 1400x757
Select picture or schematic to display from thumbnails on the right and click for download.
For model Premiere Automatic 22RB484 /62, Philips Finland - see also Fenno and TeRate

Country:  Finland
Manufacturer / Brand:  Philips Finland - see also Fenno and TeRate
Year: 1968/1969 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 11: BF195 BF195 BF195 BF194 BF194 BF195 BC149 BC148 AC126 AC187 AC188 BA102 AA119 BY122 BZY94
Main principle Superheterodyne (common); ZF/IF 452/10700 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 2.7 W (unknown quality)
from Radiomuseum.org Model: Premiere Automatic 22RB484 /62 - Philips Finland - see also
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 550 x 175 x 154 mm / 21.7 x 6.9 x 6.1 inch
Notes

Sendervorwahl durch 3 Stationstasten auf UKW.

  • LW: 375 - 150 KHz
  • MW1: 1410 - 512 KHz
  • MW2: 1620 - 1400 KHz
  • KW: 10 - 6 MHz
  • UKW: 87,5 - 104 MHz
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Wolfgang Bauer. See "Data change" for further contributors.
