Prince deluxe 4 Transmains RL346 15RL346 /01R

Prince deluxe 4 Transmains RL346 15RL346 /01R; Philips; Calcutta (ID = 2372366) Radio

Prince deluxe 4 Transmains RL346 15RL346 /01R; Philips; Calcutta (ID = 2372367) Radio

Prince deluxe 4 Transmains RL346 15RL346 /01R; Philips; Calcutta (ID = 2372368) Radio

Prince deluxe 4 Transmains RL346 15RL346 /01R; Philips; Calcutta (ID = 2372369) Radio
Prince deluxe 4 Transmains RL346 15RL346 /01R; Philips; Calcutta (ID = 1721279) Radio Prince deluxe 4 Transmains RL346 15RL346 /01R; Philips; Calcutta (ID = 1721280) Radio
Prince deluxe 4 Transmains RL346 15RL346 /01R; Philips; Calcutta (ID = 1721281) Radio Prince deluxe 4 Transmains RL346 15RL346 /01R; Philips; Calcutta (ID = 2372365) Radio
Prince deluxe 4 Transmains RL346 15RL346 /01R; Philips; Calcutta (ID = 1721282) Radio Prince deluxe 4 Transmains RL346 15RL346 /01R; Philips; Calcutta (ID = 1721283) Radio
Prince deluxe 4 Transmains RL346 15RL346 /01R; Philips; Calcutta (ID = 1721284) Radio Prince deluxe 4 Transmains RL346 15RL346 /01R; Philips; Calcutta (ID = 1721285) Radio
Prince deluxe 4 Transmains RL346 15RL346 /01R; Philips; Calcutta (ID = 1721286) Radio Prince deluxe 4 Transmains RL346 15RL346 /01R; Philips; Calcutta (ID = 1721287) Radio
Use red slider bar for more.
Prince deluxe 4 Transmains RL346 15RL346 /01R; Philips; Calcutta (ID = 1721279) Radio
Philips; Calcutta: Prince deluxe 4 Transmains RL346 15RL346 /01R [Radio] ID = 1721279 933x559
Select picture or schematic to display from thumbnails on the right and click for download.
For model Prince deluxe 4 Transmains RL346 15RL346 /01R, Philips; Calcutta:
Thanks for technical assistance Első Zalai Rádiómúzeum Alapítvány ( radio-muzeum.hu), First Zala County Radio Museum Foundation, Hungary, Zalaegerszeg.

Country:  India
Manufacturer / Brand:  Philips; Calcutta
Year: 1975 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: BF194 BF195 BF195 BC148 BC158 AC127 AC128 OA79 1N66
Main principle Superheterodyne (common)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Line / Batteries (any type) / 230 / R20: 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Prince deluxe 4 Transmains RL346 15RL346 /01R - Philips; Calcutta
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 280 x 160 x 75 mm / 11 x 6.3 x 3 inch
Notes

Prince deluxe 4 Transmains has an internal loop antenna for short-wave reception. It is also possible to connect an external antenna. The receiver has a surprisingly good short-wave reception sensitivity.

Model page created by Sandor Selyem-Tóth. See "Data change" for further contributors.
