• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1965–1967

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 111749

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 14

• Valves / Tubes
• PC900 PCF801 PCF201 PCF200 PCL84 PCL86 PL84 PCH200 PCF802 PL500 PY81 DY87 PCL85 A47-11W

• Number of Transistors
• 3

• Semiconductors
• AF186 AF186 AF126

• Main principle
• Superheterodyne (common)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 16.6 cm = 6.5 inch

• Material
• Wooden case

• from Radiomuseum.org
• Model: Raffael Automatic 19TX500A - Philips; Eindhoven tubes

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 520 x 420 x 320 mm / 20.5 x 16.5 x 12.6 inch

• Notes

• 19" B/W TV with CCIR tuner; VHF channels 2 through 11; UHF. 12 diodes. Power consumption 180 W.

  Speaker AD3729AM (800 Ohms).

  Chassis identical to Philips 23TX501A.

• Net weight (2.2 lb = 1 kg)
• 17 kg / 37 lb 7.1 oz (37.445 lb)

• Source of data
• Handbuch VDRG 1965/1966

• Mentioned in
• - - Manufacturers Literature

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
