Regent W 1852

Regent W 1852; Philips; Budapest (ID = 234374) Radio
Regent W 1852; Philips; Budapest (ID = 380246) Radio Regent W 1852; Philips; Budapest (ID = 474026) Radio
Regent W 1852; Philips; Budapest (ID = 2146198) Radio
Use red slider bar for more.
Regent W 1852; Philips; Budapest (ID = 380246) Radio
Philips; Budapest: Regent W 1852 [Radio] ID = 380246 759x622
Select picture or schematic to display from thumbnails on the right and click for download.
For model Regent W 1852, Philips; Budapest
Country:  Hungary
Manufacturer / Brand:  Philips; Budapest
Year: 1936–1938 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: AK2 AF3 AB2 AF7 VT8 AL5 EZ4
Main principle Superheterodyne (common); ZF/IF 128 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet.
Power out
from Model: Regent W 1852 - Philips; Budapest
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes Glimm-Abstimmanzeigeröhre VT8. Ortssender.
Price in first year of sale 499.00 Pengö
Mentioned in Rádiókészülékek Kapcsolásai 1936-56

Model page created by Folkert Rothe. See "Data change" for further contributors.
