• Country
• Germany

• Manufacturer / Brand
• Philips Radios - Deutschland

• Year
• 1960–1965

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 24222

• • Brand: Deutsche Philips-Ges.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• EF86 ECC83 ECL82 EZ80 EM84

• Number of Transistors

• Semiconductors
• OA85

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220; 240 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9.6 cm = 3.8 inch

• Power out
• 2.5 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: RK14 EL3515D /32c - Philips Radios - Deutschland

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 350 x 170 x 300 mm / 13.8 x 6.7 x 11.8 inch

• Notes

• Diode: OA70.
  Vierspur; 9,5 cm/s. Spulen-Ø 18 cm.

  Stereowiedergabe mit Zusatzverstärker EL3774 möglich.

• Net weight (2.2 lb = 1 kg)
• 8 kg / 17 lb 9.9 oz (17.621 lb)

• Price in first year of sale
• 399.00 DM

• External source of data
• Erb

• Source of data
• HdB d.Rdf-& Ferns-GrH 1961/62
