Sound-Machine D8734 /00 /02 /05 ab WR01

Sound-Machine D8734 /00 /02 /05; Philips - Österreich (ID = 2157531) Radio

Sound-Machine D8734 /00 /02 /05; Philips - Österreich (ID = 2157532) Radio

Sound-Machine D8734 /00 /02 /05; Philips - Österreich (ID = 2157533) Radio

Sound-Machine D8734 /00 /02 /05; Philips - Österreich (ID = 2157534) Radio

Sound-Machine D8734 /00 /02 /05; Philips - Österreich (ID = 2157556) Radio
Sound-Machine D8734 /00 /02 /05; Philips - Österreich (ID = 1640717) Radio Sound-Machine D8734 /00 /02 /05; Philips - Österreich (ID = 1640718) Radio
Sound-Machine D8734 /00 /02 /05; Philips - Österreich (ID = 2157530) Radio Sound-Machine D8734 /00 /02 /05; Philips - Österreich (ID = 1457430) Radio
Sound-Machine D8734 /00 /02 /05; Philips - Österreich (ID = 1457431) Radio Sound-Machine D8734 /00 /02 /05; Philips - Österreich (ID = 1457433) Radio
Sound-Machine D8734 /00 /02 /05; Philips - Österreich (ID = 1457434) Radio
Use red slider bar for more.
Sound-Machine D8734 /00 /02 /05; Philips - Österreich (ID = 1640717) Radio
Philips - Österreich: Sound-Machine D8734 /00 /02 /05 [Radio] ID = 1640717 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sound-Machine D8734 /00 /02 /05 ab WR01, Philips - Österreich:
../02 // Eby auction by user concept-car-design 251470021251

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1983/1984 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present. BC337 BC548 BC549 BC550 BC558 BD436 BF495 2SK168 AN7410 IR2E02 NE532 AN7166 TDA2320 TEA5570 U471B
Main principle Superheterodyne (common); ZF/IF 468/10700 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Cassette-Recorder or -Player
Power type and voltage Line plus power jack, mostly with battery or storage battery / 220 or 240 / 12 / 10 × 1,5 Volt
Loudspeaker 4 Loudspeakers
Power out
from Radiomuseum.org Model: Sound-Machine D8734 /00 /02 /05 [ab WR01] - Philips - Österreich
Material Plastics (no bakelite or catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 770 x 300 x 180 mm / 30.3 x 11.8 x 7.1 inch
Notes

Jeder Transistor nur einmal erwähnt.

Wie Philips D8734 /00 /02 /05, aber mit geänderter Endstufe und anderem Printlayout.
Die komplette Servicedoku, bis auf die erwähnte Änderung, befindet sich bei diesem Modell.

Mentioned in -- Original prospect or advert (Philips Katalog 1983)
Literature/Schematics (1) -- Original-techn. papers.
