Stereomaster Console 03RF563 /00 /01

Philips - Österreich

  • Year
  • 1966/1967
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 73865

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Number of Transistors
  • 7
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz
  • Tuned circuits
  • 6 AM circuit(s)     9 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Details
  • Changer (Record changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 220; 240 Volt
  • Loudspeaker
  • 2 Loudspeakers
  • Power out
  • 2.8 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Stereomaster Console 03RF563 [/00 /01] - Philips - Österreich
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 1043 x 834 x 390 mm / 41.1 x 32.8 x 15.4 inch
  • Notes
  • 2 Ausführungen:
    /00 = nuß dunkel hochglänzend
    /01 = teak natur matt
    Eingebauter Stereodecoder
    2 Magische Bänder für Feldstärke- und Stereoanzeige
    Eingebauter Plattenwechsler Philips 22GC035.
  • Source of data
  • Radiokatalog Band 2, Ernst Erb
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Wolfgang Bauer. See "Data change" for further contributors.
