Super-Inductance 638A

Super-Inductance 638A; Philips - Polskie (ID = 2221920) Radio Super-Inductance 638A; Philips - Polskie (ID = 2221921) Radio
Super-Inductance 638A; Philips - Polskie (ID = 2221922) Radio Super-Inductance 638A; Philips - Polskie (ID = 2221923) Radio
Super-Inductance 638A; Philips - Polskie (ID = 2222260) Radio
Use red slider bar for more.
Super-Inductance 638A; Philips - Polskie (ID = 2221920) Radio
Philips - Polskie: Super-Inductance 638A [Radio] ID = 2221920 1195x1500
Select picture or schematic to display from thumbnails on the right and click for download.
For model Super-Inductance 638A, Philips - Polskie Zaklady Philips:
Photo of my radio

Country:  Poland
Manufacturer / Brand:  Philips - Polskie Zaklady Philips
Year: 1934/1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: AF2 AF2 AB1 E446 E463 506
Main principle TRF without regeneration; 2 AF stage(s)
Tuned circuits 4 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 40-100 Hz: 103; 111; 118; 127; 135; 143; 155; 196; 210; 225; 240; 253 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 20 cm = 7.9 inch
Power out
from Radiomuseum.org Model: Super-Inductance 638A - Philips - Polskie Zaklady
Material Wooden case
Shape Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
Dimensions (WHD) 375 x 470 x 215 mm / 14.8 x 18.5 x 8.5 inch
Notes

See also Philips 638A for the Netherlands. More complete service information can be found at the model page for France here.

There is also a model 6-38A of 1937/1938.

Mentioned in -- Original prospect or advert
Literature/Schematics (1) -- Collector info (Sammler)

Model page created by Tomasz Szczesniak. See "Data change" for further contributors.



All listed radios etc. from Philips - Polskie Zaklady Philips
Here you find 46 models, 31 with images and 21 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
