TI1721A /05

TI1721A /05; Philips Italy; (ID = 1718171) Television

TI1721A /05; Philips Italy; (ID = 1718172) Television

TI1721A /05; Philips Italy; (ID = 1718173) Television

TI1721A /05; Philips Italy; (ID = 1718174) Television

TI1721A /05; Philips Italy; (ID = 1718175) Television

TI1721A /05; Philips Italy; (ID = 1718176) Television
TI1721A /05; Philips Italy; (ID = 1136249) Television TI1721A /05; Philips Italy; (ID = 951276) Television
TI1721A /05; Philips Italy; (ID = 1136250) Television TI1721A /05; Philips Italy; (ID = 1136252) Television
TI1721A /05; Philips Italy; (ID = 1136253) Television TI1721A /05; Philips Italy; (ID = 1244961) Television
TI1721A /05; Philips Italy; (ID = 1840939) Television
Use red slider bar for more.
TI1721A /05; Philips Italy; (ID = 1136249) Television
Philips Italy;: TI1721A /05 [Television] ID = 1136249 933x738
Select picture or schematic to display from thumbnails on the right and click for download.
For model TI1721A /05, Philips Italy; Milano (MI)

Country:  Italy
Manufacturer / Brand:  Philips Italy; Milano (MI)
Year: 1954 ? Category: Television Receiver (TV) or Monitor
Valves / Tubes 21: MW43-64
Main principle Superheterodyne (common); ZF/IF 45900 kHz
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: TI1721A /05 - Philips Italy; Milano MI
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 540 x 490 x 550 mm / 21.3 x 19.3 x 21.7 inch
Notes

17" CRT.

Altoparlante tipo 9768X

Su alcuni modelli è montato il tubo Philips MW 43-69 uguale al MW 43-64 ma alluminato.

Source of data -- Original prospect or advert
Mentioned in Video Libro 2ª ed. 1955
Literature/Schematics (1) Schemario tv "Il Rostro" volume III

Model page created by Alessandro De Poi. See "Data change" for further contributors.
