Tizian Luxus Truhe 23RD392A
Philips Radios - Deutschland
- Country
- Germany
- Manufacturer / Brand
- Philips Radios - Deutschland
- Year
- 1963 ??
- Category
- Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
- Radiomuseum.org ID
- 222960
-
- Brand: Deutsche Philips-Ges.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 27
- Valves / Tubes
- PCC189 PCF86 PC88 PC86 EF183 EF184 PCL84 ECH84 EF184 PCL86 ECH84 PCF802 PL500 PY88 DY86 PF86 PCL85 AW59-11W ECC85 ECH81 EAF801 EF184 ECC808 ECL86 ECL86 EM87 EM87
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 6 AM circuit(s) 12 FM circuit(s)
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- 2 Loudspeakers / Ø 19 cm = 7.5 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Tizian Luxus Truhe 23RD392A - Philips Radios - Deutschland
- Shape
- Console with any shape - in general
- Dimensions (WHD)
- 77 x 94 x 43 inch / 1956 x 2388 x 1092 mm
- Notes
-
Als Plattenspieler ist der SC 15 eingebaut.
Als Fernbedienungen konnten entweder Typ 60 oder Typ 63 ( mit Tonausschaltung und Ohrhörer) angeschlossen werden.
- Net weight (2.2 lb = 1 kg)
- 40 kg / 88 lb 1.7 oz (88.106 lb)
- Mentioned in
- Sammel-Preisliste 64/65
- Author
- Model page created by Egon Strampe. See "Data change" for further contributors.
