Tragbare UK Sende-Empfangsanlage CAW Phi 1UK43 / DR25b1x
Philips; Eindhoven (tubes international!); Miniwatt
- Country
- Netherlands
- Manufacturer / Brand
- Philips; Eindhoven (tubes international!); Miniwatt
- Year
- 1944 ?
- Category
- Military Transceiver (TRX)
- Radiomuseum.org ID
- 180273
- Number of Tubes
- 4
- Main principle
- Transceiver
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Powered by external power supply or a main unit. / 4,5 & 150 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: Tragbare UK Sende-Empfangsanlage CAW Phi 1UK43 / DR25b1x - Philips; Eindhoven tubes
- Shape
- Portable set > 8 inch (also usable without mains)
- Notes
-
Philips NL, Tragbare UK Sende-Empfangsanlage, Bauart CAW, Kriegsmarinenbezeichnung Phi 1 UK 43, Philips interne Type: DR25b1x.
37.5 - 46.2 MHz, A3, 1 W pout, Betrieb mit Trockenbatterien oder Universal Speisungsgerät Type U.O.R.1, Unterschied zur Phi 1 UK 41 mit DR25b1x Typennummer derzeit nicht bekannt.
- Net weight (2.2 lb = 1 kg)
- 15 kg / 33 lb 0.6 oz (33.04 lb)
- Mentioned in
- Funkgeschichte der GFGF (27. JG, Aug/Sept. 2004, Nr. 156, S159ff)
- Literature/Schematics (1)
- RADIOBOTE, Österr. (Heft 30/2010, S.20 ff, Gerätebeschreibung)
- Author
- Model page created by a member from A. See "Data change" for further contributors.
