Video Cassette Recorder VR6561 /02R

Video Cassette Recorder VR6561 /02R; Philips - Österreich (ID = 1416042) R-Player Video Cassette Recorder VR6561 /02R; Philips - Österreich (ID = 1415616) R-Player
Video Cassette Recorder VR6561 /02R; Philips - Österreich (ID = 1415615) R-Player Video Cassette Recorder VR6561 /02R; Philips - Österreich (ID = 1416044) R-Player
Video Cassette Recorder VR6561 /02R; Philips - Österreich (ID = 1416045) R-Player Video Cassette Recorder VR6561 /02R; Philips - Österreich (ID = 1416047) R-Player
Video Cassette Recorder VR6561 /02R; Philips - Österreich (ID = 1416049) R-Player Video Cassette Recorder VR6561 /02R; Philips - Österreich (ID = 1416050) R-Player
Use red slider bar for more.
Video Cassette Recorder VR6561 /02R; Philips - Österreich (ID = 1416042) R-Player
Philips - Österreich: Video Cassette Recorder VR6561 /02R [R-Player] ID = 1416042 933x375
Select picture or schematic to display from thumbnails on the right and click for download.
For model Video Cassette Recorder VR6561 /02R, Philips - Österreich

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1987 ? Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Superheterodyne (common)
Wave bands VHF incl. FM and/or UHF (see notes for details)
Details Video-Taperecorder/-Player
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Video Cassette Recorder VR6561 /02R - Philips - Österreich
Material Metal case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 420 x 84 x 325 mm / 16.5 x 3.3 x 12.8 inch
Notes




Video Signal System PAL: R/P, SECAM: R/P
Videostandard: VHS
Tuner equipped: Yes HF Output: Yes
Timer: Yes Color: Yes
Insert-Cut: - Controllable by Editing-System: No
Timebas Corrector: No RGB Video In/Out: -
Composite (FBAS) Video In/Out: Yes Component Video In/Out: No
S-Video In/Out: No Signal to Noise Video: 46db
Horizontal Resol. black/white: >240 Horizontal Resolution Color: -
Dropout compensator: Yes Wow and Flutter lin. audiotrack: <0,2%
No. of Audiochannels linear track: 1 No. of Audiochannels helical track: -
Signal to Noise linear Audio track: 43db Signal to Noise helical Audio track: -
Audio Out Asym Audio In Asym
crosstalk lin. Audio track - crosstalk heli. Audio track -

Audio Frequency Response : 40 - 10.000Hz
Remote Control: IR



VPS

Net weight (2.2 lb = 1 kg) 7.5 kg / 16 lb 8.3 oz (16.52 lb)

Model page created by Jürgen Küting. See "Data change" for further contributors.
