VCR Video Cassette Recorder N1702 /00 /15 /43 /45 /65

VCR Video Cassette Recorder N1702 /00 /15 /43 /45 /65; Philips - Österreich (ID = 317335) R-Player
VCR Video Cassette Recorder N1702 /00 /15 /43 /45 /65; Philips - Österreich (ID = 183588) R-Player VCR Video Cassette Recorder N1702 /00 /15 /43 /45 /65; Philips - Österreich (ID = 469878) R-Player
VCR Video Cassette Recorder N1702 /00 /15 /43 /45 /65; Philips - Österreich (ID = 183518) R-Player VCR Video Cassette Recorder N1702 /00 /15 /43 /45 /65; Philips - Österreich (ID = 183519) R-Player
VCR Video Cassette Recorder N1702 /00 /15 /43 /45 /65; Philips - Österreich (ID = 1423472) R-Player VCR Video Cassette Recorder N1702 /00 /15 /43 /45 /65; Philips - Österreich (ID = 1423473) R-Player
VCR Video Cassette Recorder N1702 /00 /15 /43 /45 /65; Philips - Österreich (ID = 1423474) R-Player VCR Video Cassette Recorder N1702 /00 /15 /43 /45 /65; Philips - Österreich (ID = 1423475) R-Player
VCR Video Cassette Recorder N1702 /00 /15 /43 /45 /65; Philips - Österreich (ID = 1658502) R-Player
Use red slider bar for more.
VCR Video Cassette Recorder N1702 /00 /15 /43 /45 /65; Philips - Österreich (ID = 183588) R-Player
Philips - Österreich: VCR Video Cassette Recorder N1702 /00 /15 /43 /45 /65 [R-Player] ID = 183588 933x506
Select picture or schematic to display from thumbnails on the right and click for download.
For model VCR Video Cassette Recorder N1702 /00 /15 /43 /45 /65, Philips - Österreich

Country:  Austria
Manufacturer / Brand:  Philips - Österreich
Year: 1978/1979 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands Wave Bands given in the notes.
Details Video-Taperecorder/-Player
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker
Power out
from Radiomuseum.org Model: VCR Video Cassette Recorder N1702 /00 /15 /43 /45 /65 - Philips - Österreich
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 560 x 160 x 370 mm / 22 x 6.3 x 14.6 inch
Notes
Video Signal System (Playback): CCIR PAL: [X] SECAM: [_] NTSC: [_] other: [_]
Video Signal System (Record): CCIR PAL: [X] SECAM: [_] NTSC: [_] other: [_]
Videostandard: VCR-Longplay
Tuner equipped: Yes HF Output: Yes
Timer: Yes Color: Yes
Insert-Cut: No Controllable by Editing-System: No
Output Level: - RGB Video Output: No
Composite (FBAS) Video Out: No Component Video Output: No
S-Video Output: No Signal to Noise Video: -
Horizontal Resol. black/white: >240l. Horizontal Resolution Color: 240l.
Dropout compensator: Yes Wow and Flutter lin. audiotrack: -
No. of Audiochannels linear track: 1 No. of Audiochannels helical track:

0
Signal to Noise linear Audio track: - Signal to Noise helical Audio track: -
Symmetrical Audio Out No Non-symmetrical Audio Out No












Audio Frequency Response: -
Timebase Corrector: No
Remote Control: No

5 Ausführungen:
/00 = CCIR/PAL-Norm
/15 = PAL-System A.I. (Tonträger + 6 MHz)
/43 = wie /15 aber mit Band III, Netzspannung 240 Volt
/45 = mit Sonderkanaltuner
/65 = wie /15 aber Netzspannung 220 Volt
Philips N1702;
Net weight (2.2 lb = 1 kg) 16 kg / 35 lb 3.9 oz (35.242 lb)
Price in first year of sale 2'000.00 DM
Literature/Schematics (1) -- Original-techn. papers.

Model page created by Michael John. See "Data change" for further contributors.
