• Country
• Netherlands

• Manufacturer / Brand
• Philips; Eindhoven (tubes international!); Miniwatt

• Year
• 1969 ?

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 240728

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 16

• Valves / Tubes
• PCL86 PL84 PC900 PCF801 PCF201 PCF200 PCF200 PFL200 PCF80 PCF802 PL504 PY88 DY87 PCH200 PCL85 A65-11W

• Number of Transistors
• 9

• Semiconductors
• AF186 AF186 BC107 AF121 AF121 AF121 AC126 AC127 AC125

• Main principle
• Superheterodyne (common); 2 AF stage(s)

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 110; 127; 220 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: X25T604 /00 /07 - Philips; Eindhoven tubes

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 810 x 540 x 460 mm / 31.9 x 21.3 x 18.1 inch

• Notes
• • Transformerless audio output stage.
  • CCIR, Belgian and French standards.
  • VHF (tuner 4822 118 00169): E2-E11, F6, F8a.
  • UHF (tuner 4822 118 00309): 470-890 MHz.
  • Contains semiconductor diodes: 1 x BY100, 1 x OA47, 1 x OA90, 1 x OA85, 4 x OA81, 3 x BA100.
  Basically the same TV as X19T602 /00. For the differences see the technical document uploaded to this model.

• Mentioned in
• -- Original-techn. papers.

• Author
• Model page created by Radiomuseum Olen Museum. See "Data change" for further contributors.
