Radioplayer 6515
Philips Australia
- Country
- Australia
- Manufacturer / Brand
- Philips Australia
- Year
- 1937
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 170869
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superhet with RF-stage; ZF/IF 175 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Storage and/or dry batteries / 135 & 2 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Radioplayer 6515 - Philips Australia
- Shape
- Tablemodel, with any shape - general.
- Notes
- This radio could be powered from a 6 volt storage battery with the use of a Philips type 148 vibrator unit.
- Price in first year of sale
- 30.00 Aus£
- Circuit diagram reference
- Australian Official Radio Service Manual Vol. I I
- Literature/Schematics (1)
- Radio Trade Annual 1939 P288.
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
